Conical Galvanized Steel 16m Power Transmission Poles

Jiangsu hongguang steel pole co.,ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Conical Galvanized Steel 16m Power Transmission Poles from wholesalers

    Buy cheap Conical Galvanized Steel 16m Power Transmission Poles from wholesalers
    • Buy cheap Conical Galvanized Steel 16m Power Transmission Poles from wholesalers
    • Buy cheap Conical Galvanized Steel 16m Power Transmission Poles from wholesalers

    Conical Galvanized Steel 16m Power Transmission Poles

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-SP-110KV
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : L/C, T/T or Western Union
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 2 weeks per container after PO / drawing / prepayment confirmed
    • Product Details
    • Company Profile

    Conical Galvanized Steel 16m Power Transmission Poles

    Galvanized Steel Poles Steel Transmission Poles Steel Power Pole Power Distribution Poles

    Product Description:


    Products
    • Galvanized Steel Poles Steel Transmission Poles Steel Power Pole Power Distribution Poles

    Application
    • Electrical Power Transformer Substation

    Standrad
    • NEA Standard

    Painting
    • According to clients' request

    Base plate
    • Square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.

    Galvanization
    • Hot dip galvanization of substation structure is in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.
    Life Period
    • More than 25 years, it is according to installing environment

    Product Advantages:

    1). Short Construction Cycle
    2). Less Land Occupation
    3). Low Overall Cost
    4). Easy Installation and Maintenance
    5). Weather Resistance
    6). Anti-corrosion
    7). ODM & OEM are available
    8). Capable to Handle Volume Orders
    9). Provide Professional Design by Our Experienced R&D Engineers

    Engineering and Design Management:

    “Design and technology,professional and common, software and hardware” is JSHG‘s electric post design philosophy. We have established a close cooperative relationship with design institutions and companies in the same industry. Through close communication and explorations, our company took in advanced design concept, introducing domestic and foreign first-class design software, and attracting high-quality personnel.


    In the R&D Department, there are many experienced senior research & design staff and rigid development network, which ensure our design proposals meet customer demand, even exceed their expectations.


    Since the establishment, JSHG have put forward thousands of design proposals covering several industries and fields, such as power transmission industry, telecommunication industry, lighting industry, etc, which provides complete and strong technical support and service assurance.


    Manufacturing:

    Raw material: Q235 or Q345 in China. We get the raw material checked in our lab test room. Silicon less than2%. We have carbon and sulfur analyzer to check the elements of the steel sheet. We'll return the steel if they are unqualified. So in this way, we can control the quality of the steel poles from the first beginning.

    Our factory owns advanced production lines and machines including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All insure us to produce steel poles with the best quality.

    After the fabrication process as cutting plate, bending, forming, automatic welding, drilling holes, we get poles checked before galvanized, hot dip galvanized and powder coating and finally we get poles checked according to client's requirements.


    Product Show:

    Steel Pole of National Electrification Administration (Philippines)
    Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
    Height
    (ft)
    Thickness
    (mm)
    Top diameter
    (mm)
    Butt diameter
    (mm)
    Design Load
    (kgf)
    Yield Stress
    (MPa)
    Zinc Coating
    (micron)
    25
    2.5
    120
    152
    300
    345
    86
    30
    3.0
    127
    226
    500
    345
    86
    35
    3.0
    127
    248
    500
    345
    86
    40
    3.0
    127
    317
    500
    345
    86
    45
    4.0
    127
    328
    750
    345
    86
