45FT Polygonal Conical Hot Dip Galvanized Steel Pole With Climbing Rung Q345

Jiangsu hongguang steel pole co.,ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 45FT Polygonal Conical Hot Dip Galvanized Steel Pole With Climbing Rung Q345 from wholesalers

    Buy cheap 45FT Polygonal Conical Hot Dip Galvanized Steel Pole With Climbing Rung Q345 from wholesalers
    • Buy cheap 45FT Polygonal Conical Hot Dip Galvanized Steel Pole With Climbing Rung Q345 from wholesalers
    • Buy cheap 45FT Polygonal Conical Hot Dip Galvanized Steel Pole With Climbing Rung Q345 from wholesalers

    45FT Polygonal Conical Hot Dip Galvanized Steel Pole With Climbing Rung Q345

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-SP
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : L/C, T/T or Western Union
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 2 weeks per container after PO/drawing/prepayment confirmed
    • Product Details
    • Company Profile

    45FT Polygonal Conical Hot Dip Galvanized Steel Pole With Climbing Rung Q345

    45FT Polygonal Conical Hot Dip Galvanized Steel Pole With Climbing Rung Q345

    Product Description:


    Manufacturing:

    Raw material: Q235 or Q345 in China. We get the raw material checked in our lab test room. Silicon less than2%. We have carbon and sulfur analyzer to check the elements of the steel sheet. We'll return the steel if they are unqualified. So in this way, we can control the quality of the steel poles from the first beginning.


    Hot dip galvanization:
    All our products must be hot dip galvanized which can keep the steel poles without rust more than 30 years.Our standard for a good hot dip galvanization steel pole is same color of the zinc coating without dent mark,no exposed iron and hang of zinc of defect. Normally speaking,the thickness of the zinc coating is up to the materials thickness.The thicker the material is, the thicker the zinc coating will be.


    Production Process:


    • Raw material test

    • Cutting

    • Bending

    • Welding (longitudinal )

    • Dimension verify

    • Flange welding

    • Hole drilling

    • Calibration

    • Deburr

    • Galvanization or powder coating or Bituminous painting

    • Recalibration

    • Packages

    45FT Polygonal Conical Hot Dip Galvanized Steel Pole With Climbing Rung Q345

    Product Specification:


    Products
    • 45FT Polygonal Conical Hot Dip Galvanized Steel Pole With Climbing Rung Q345
    Application
    • Power transmission and distribution Line
    Material
    • Q345
    Galvanization
    • Hot dip galvanized in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.
    • Average thickness ≥86um
    Welding
    • According to AWS D 1.1, CO2 welding or submerged arc auto methods
    Shape
    • Octagonal
    Joint
    • Overlap joint

    Painting

    • Bitumen Painted according to customer's requirement

    Once Forming

    • 12m Once forming without joint

    Standard Accessories:

    - Top Cap
    - Butt Plate
    - Standard hole on X-X , Y-Y , Z-Z.
    - Grounding Nuts & Bolts


    Others Standard poles 25FT, 30FT, 35FT, 40FT,45FT


    Height

    (ft)

    Thickness

    (mm)

    Butt Diameter

    (mm)

    Tip Diameter

    (mm)

    Design Load

    (kg)

    Yield Stress

    (MPA)

    Zinc Coating

    (microns)

    252.515212030034586
    303.022612750034586
    353.024812750034586
    403.031712750034586
    453.032812750034586

    Contact Us:

    Jiangsu Hongguang Steel Pole Co., Ltd.
    Address: Wanshi Industrial Zone, Yixing City, Jiangsu Pro., P.R.China, 214212
    Telphone: +86 510 878 441 56
    Fax: +86 510 878 435 28
    Trade manager ID: cnhgsteelpole
    Skype: tangjia870124

    Company youtube link: https://youtu.be/C9sHcnm3RKI

    Please feel free to contact us!
