30ft Polygonal Hot Dip Galvanized Pole With Min Yield Strength 345 Mpa

Jiangsu hongguang steel pole co.,ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 30ft Polygonal Hot Dip Galvanized Pole With Min Yield Strength 345 Mpa from wholesalers

    Buy cheap 30ft Polygonal Hot Dip Galvanized Pole With Min Yield Strength 345 Mpa from wholesalers
    • Buy cheap 30ft Polygonal Hot Dip Galvanized Pole With Min Yield Strength 345 Mpa from wholesalers
    • Buy cheap 30ft Polygonal Hot Dip Galvanized Pole With Min Yield Strength 345 Mpa from wholesalers

    30ft Polygonal Hot Dip Galvanized Pole With Min Yield Strength 345 Mpa

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-SP-110KV
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : L/C, T/T or Western Union
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 2 weeks per container after PO / drawing / prepayment confirmed
    • Product Details
    • Company Profile

    30ft Polygonal Hot Dip Galvanized Pole With Min Yield Strength 345 Mpa

    Polygonal Hot Dip Galvanized Power Transmission Pole with Min Yield Strength 345 Mpa

    Product Description:


    Products
    • Polygonal Hot Dip Galvanized Power Transmission Pole with Min Yield Strength 345 Mpa

    Application
    • Electrical Power transmission and distribution line

    Standrad
    • Philippines NEA Standard

    Delivery Time
    • 2 weeks per container after PO/drawing/prepayment confirmed

    Life Period
    • More than 25 years, it is according to installing environment

    Packaging Details
    • Covered by Plastic Wrap or Mat or according to client's requests.
    • The Loading Pcs of Each Container could be calculated according to client's specification and data.
    Export Foreign Country
    • America ,Morocco,Sir Lanka ,Russia, Jordan,Guyana,Nigeria, Australia, Spain, Indonesia, Singapore, the Philippines, Kenya,etc

    Product Detial:


    National Electrification Administration (Philippines)
    Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT


    Height(ft)

    Thickness(mm)

    Butt Diameter(mm)

    Top Diameter(mm)

    Design Load(kg)

    Yield Stress(MPA)

    Zinc Coating(microns)

    25

    2.5

    152

    120

    300

    345

    86

    30

    3.0

    226

    127

    500

    345

    86

    35

    3.0

    248

    127

    500

    345

    86

    40

    3.0

    317

    127

    500

    345

    86


    Quality Control Management:


    JSBS has passed the ISO 9001 quality management system. And we have our own Lab to do the chemical and mechanical test. For instance, we test the raw material component content and the strength when we purchase the raw material. And if the material does not pass the test, we’ll not use it to produce our steel poles. Therefore, customers can rest assured that we always manufacture the good quality poles. Meanwhile, our factory has the AMT ( Advanced Manufacturing Technology ), all the purposes are to provide high-quality poles all over the world.



    Our Service


    • Reply within 24 Working Hours
    • Factory Direct Sale
    • More than 15 Years Design & Manufacture Experience
    • Capable to Handle Volume Orders
    • High-Quality and Low-Price Product
    • Provide Professional Design by Our Experienced R&D Engineers
    • Rich Exporting Experience
    • ODM, OEM Acceptable
    • Technical Support by E-mail
    • Calling service

    Contact Us:


    Jiangsu Hongguang Steel Pole Co., Ltd.

    Address: Wanshi Industrial Zone, Yixing City, Jiangsu Pro., P.R.China, 214212

    Telphone: +86 510 878 441 56

    Fax: +86 510 878 435 28

    Trade manager ID: cnhgsteelpole

    Skype: tangjia870124


    Please feel free to contact us!
