9m 250 Dan 8 Sides Electric Power Pole Anti-Corrosive Steel For Transmission Line

Jiangsu hongguang steel pole co.,ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 9m 250 Dan 8 Sides Electric Power Pole Anti-Corrosive Steel For Transmission Line from wholesalers

    Buy cheap 9m 250 Dan 8 Sides Electric Power Pole Anti-Corrosive Steel For Transmission Line from wholesalers
    • Buy cheap 9m 250 Dan 8 Sides Electric Power Pole Anti-Corrosive Steel For Transmission Line from wholesalers
    • Buy cheap 9m 250 Dan 8 Sides Electric Power Pole Anti-Corrosive Steel For Transmission Line from wholesalers

    9m 250 Dan 8 Sides Electric Power Pole Anti-Corrosive Steel For Transmission Line

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-SP
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : L/C, T/T or Western Union
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 2 weeks per container after PO/drawing/prepayment confirmed
    • Product Details
    • Company Profile

    9m 250 Dan 8 Sides Electric Power Pole Anti-Corrosive Steel For Transmission Line

    9m 250daN 8 Sides Anti-corrosive Steel Electrical Power Pole for Transmission Line

    Product Specification:


    Products

    • 9m 250daN 8 Sides Anti-corrosive Steel Electrical Power Pole for Transmission Line

    Application

    • Overhead Transmission Line Project

    Steel materials

    • Hot Roll Steel Q345 and others equivalent steel material ASTM GR50, Minmum Yield Strength: 345MPA

    Appearance

    • Hot-dip galvanized in accordance with ASTM A123. The average thickness of Zinc is 86um.

    Pole Shape

    • Octagonal ( 8 sides)

    Quality Standard

    • ISO9001:2008, AAA credit rating, etc

    Export country

    • Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc

    Inquiry Information


    • Pole top design load
    • Where is the position of the load , the distance from the top
    • The wind Speed
    • How will the wire distribute
    • Pole type with Burial Type or Base Plate type
    • The connections mode , use slip joint or flange
    • Others we can further more discuss when we need.


    Accessories:

    1. Pole Shaft
    2. Top Cap
    3. Base Plate
    4. Butt Strip Plate
    5.
    CrossArm
    6. Anchor Bolts
    7. Grounding Nut & Bolts
    8. Name Plate
    9. Climbing Rungs
    10. Template
    11. Bituminous Painting if needed


    Quality Control Management:


    JSHG has passed the ISO9001 quality management system. Besides, it processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon and sulfur microcomputer analyzer etc.


    LOADING TEST



    DIAMENSION TEST



    Terms and Conditions:


    1. Price Term: EXW, FOB, CFR or CIF.

    The price includes pole shaft, base plate, crossarm and anchor bolt.
    Shipping seaport: Shanghai Seaport.
    Please provide drawings if you have so that we can calculate the accurate price for you.
    We also provide design according to your requests, if you don't have drawings.
    2. MOQ: One 40FT Container.

    3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.


    Contact Us:

    Jiangsu Hongguang Steel Pole Co., Ltd.
    Address: Wanshi Industrial Zone, Yixing City, Jiangsu Pro., P.R.China, 214212
    Telphone: +86 510 878 441 56
    Fax: +86 510 878 435 28
    Trade manager ID: cnhgsteelpole
    Skype: tangjia870124

    Please feel free to contact us!
