    40FT 3.0mm Thick Q355 Steel Tubular Pole Galvanized And Bitumen Painted

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-SP
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : L/C, T/T or Western Union
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 1 week
    • Product Details
    • Company Profile

    40FT 3.0mm Thick Q355 Steel Tubular Pole Galvanized And Bitumen Painted

    40FT 3.0mm Thick Q355 Steel Tubular Pole Galvanized And Bitumen Painted

    Product Description:


    Jiangsu Hongguang Steel Pole Co., Ltd has passed the ISO 9001 quality management system. And we have our own Lab to do the chemical and mechanical test. For example, we test the raw material component content and the strength when we purchase the raw material. And if the material does not pass the test,we’ll not use it to produce our poles. So customers can be assured that we always manufacture the good quality poles. Meanwhile, our factory has the AMT ( Advanced Manufacturing Technology ), all the purposes are to provide high-quality good poles all over the world.


    40FT 3.0mm Thick Q355 Steel Tubular Pole Galvanized And Bitumen Painted

    Raw Material



    Applied to the material of general-purpose steel GB/T1591-2008, Q235, Q345, Q420, Q460 used in China.



    China-GB


    America-ASTM


    Equivalent


    Q235


    Grade D


    SS400,S235JO


    Q345


    Grade50[345]


    S355JR


    Q420


    Grade60[415]


    S420NL


    Q460


    Grade65[450]


    S460NL

    Product Specification:


    Products

    • 40FT 3.0mm Thick Q355 Steel Tubular Pole Galvanized And Bitumen Painted

    Voltage Grade

    • 13.8KV

    Galvanization

    • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.

    Welding

    • According to AWS D 1.1, CO2 welding or submerged arc auto methods

    • No fissure, scar, overlap, layer or other defects

    • If customers need any other requirements of welding, we also can make adjustment ad your request

    Life Period

    • More than 25 years, it is according to installing environment

    Surface treatment

    • Hot dip galvanized Following ASTM A 123,
      color polyester power or any other standard by client required

    Advantages


    • Weather Resistance

    • Anti-corrosion

    • ODM & OEM are available

    • Capable to Handle Volume Orders

    • Provide Professional Design by Our Experienced R&D Engineers

    Product process chat
    • Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify→Flange welding →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages

    40FT 3.0mm Thick Q355 Steel Tubular Pole Galvanized And Bitumen Painted

    Product Test:


    JSHG has passed the ISO9001 quality management system. Besides, it processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon and sulfur microcomputer analyzer etc.


    Meanwhile, it has formed a scientific and strict quality management system, which effectively and strictly guarantees the quality control of products form raw material to finished products.



    NEA Standard Specification:


    Octagonal Galvanized Steel Pole 25FT, 30FT, 35FT, 40FT,45FT


    Height

    (ft)

    Thickness

    (mm)

    Butt Diameter

    (mm)

    Tip Diameter

    (mm)

    Design Load

    (kg)

    Yield Stress

    (MPA)

    Zinc Coating

    (microns)

    252.515212030034586
    303.022612750034586
    353.024812750034586
    403.031712750034586
    453.032812750034586

    Product Advantages:

    The Hot Dip Galvanized Electrical Power Steel Tubular Pole plays an important role in electrical power transmission and distribution industry. In order to meet the increasingly higher demand for steel tubular pole, our company design and produce many kinds of steel tubular pole for the power transmission and distribution system. Besides, our electrical steel tubular pole have been tested and approved by the Transmission Pole Tower Testing Station.


    Contact Us:

    Jiangsu Hongguang Steel Pole Co., Ltd.
    Address: Wanshi Industrial Zone, Yixing City, Jiangsu Pro., P.R.China, 214212
    Telphone: +86 510 878 441 56
    Fax: +86 510 878 435 28
    Trade manager ID: cnhgsteelpole
    Skype: tangjia870124

    Please feel free to contact us!
