    8-15m Light Column Steel Round Conical Street Light Poles RAL Painted ISO Passed

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-SP
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : L/C, T/T or Western Union
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 7days
    • Product Details
    • Company Profile

    8-15m Light Column Steel Round Conical Street Light Poles RAL Painted ISO Passed

    8-15m Light Column Steel Round Conical Street Light Poles RAL Painted ISO Passed


    Product Description:


    Material

    Usually Q345B/A572,minimum yield strength>=345n/mm2

    Q235B/A36,minimum yield strength>=235n/mm2
    As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52-


    Shape of Pole

    Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc.),Tubular, Tapered


    Arms
    With Single / Double / Triple Outreach Arms or Brackets


    Welding

    1.Welding complies with AWS D1.1 standard.

    2.CO2 welding or submerged arc auto methods

    3.No fissure, scar, overlap, layer or other defects

    4.Internal and external welding makes the pole more beautiful in shape

    5.If customers need any other requirements of welding, we also can make adjustment ad your request


    Base plate

    Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.


    Surface Treatment


    Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123 or AS/NZS 4680:2006

    Could be powder coated or painted according to clients' request


    Lamp power 20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz


    Torlance of the diensmtion +- 2%


    Optical assembly of lighting fixture IP 65


    Electroshock resistant protective grade Grade Ⅰ


    The casing anti-corrosion performance Class Ⅱ


    Working atmosphere of lighting fixture -35 °C~+45 °C

    8-15m Light Column Steel Round Conical Street Light Poles RAL Painted ISO Passed

    Trade Terms:


    1. Prices conditions

    Price can be FOB, CIF ,EXW, which includes pole shaft, base plate, crossarm and anchor bolt.

    Shipping seaport: Shanghai Seaport.

    Please provide drawings if you have so that we can calculate the accurate price for you.

    We also provide design according to your requests, if you don't have drawings.


    2. What will be the delivery time and what will be the mode of payment?
    We have large quantities in stock for normal type. Re special color and products sizes it needs 7days.
    The payment can be
    L/C, T/T or Western Union.


    3. Could you please send me the sample for the same. So that i could see and analyze its quality?
    Yes. We can send samples first, samples need to be charged if the value is higher.


    Product Advantages:


    Excellent performance:

    Because of the long and thin shape,closed polygonal section and apply of high strength steel material,these steel poles have excellent durability.they can withstand the extreme condition,such as the frost climate,unbalanced loads, or breaking of wire.


    Installation

    The designing weight of the steel poles are usually relatively light ,and is good for the operation,transportation,assemble and installation.


    Environment

    Since the long and thin straight line shape.the steel pole are easily intergrated into the landscape.At the protected areas(mountains),the installation of steel pole will not influence the aesthetic solution of the scenic spot


    Quality Control Management


    JSHG has passed the ISO9001 quality management system. Besides,it processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon and sulfur microcomputer analyzer etc.


    Meanwhile, it has formed a scientific and strict quality mangement system, which effectively and strictly guarantees the quality control of products form raw material to finished products.


    8-15m Light Column Steel Round Conical Street Light Poles RAL Painted ISO Passed
