    14m 800 Dan Electrical Transmission Power Pole Replacement Hot Dip Galvanization Q345

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-SP-110KV
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : L/C, T/T or Western Union
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 2 weeks per container after PO / drawing / prepayment confirmed
    MOQ : 1 set
    • Product Details
    • Company Profile

    14m 800 Dan Electrical Transmission Power Pole Replacement Hot Dip Galvanization Q345

    14m 800daN Electrical Transmission Poles Hot Dip Galvanization Q345


    Product Description:


    Products

    • 14m 800daN Electrical Transmission Poles Hot Dip Galvanization Q345

    Brackets
    • Single or double brackets are in the shape and dimension as per customers requirement

    Shape of pole

    • Round,conical,polygonal shafts are made of steel sheet that folded into required shape and welded longitudinally by automatic arc welding machine

    Material

    • Q345B/A572,minimum yield strength>=345n/mm2
      Q235B/A36,minimum yield strength>=235n/mm2

    • As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50

    Base plate

    • Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement

    Identification

    • Name plate

    Welding

    • AWS D1.1 standard.

    • CO2 welding or submerged arc auto methods

    Galvanization

    • Hot dip galvanization with thickness of 80-100µm average

    Life Period

    • More than 25 years, it is according to installing environment

    Package

    • Plastic Wrap or Mat or according to client's requests

    The hot dip galvanized power transmission pole plays an important role in electrical power transmission and distribution industry. Our company design and produce many kinds of power transmission pole for the power transmission and distribution system. Besides, our power transmission pole have been tested and approved by the Transmission Pole Tower Testing Station. In addition, our company have become a qualified supplier of SGCC and NGCP.


    The power transmission pole of our company are made from quality sheets through bending,forming, automatic welding, hot dip galvanization. We owned advanced production-line, including flatting machine, steel plate shearer, bending machine,auto-closed up machine, submerged arc welding machine and powder coating line, and our workmanship and quality control was achieved high opinion from our clients.


    14m 800 Dan Electrical Transmission Power Pole Replacement Hot Dip Galvanization Q345


    Product Process Flat Chat:


    Raw material test → Cutting→Bending →Weldng (longitudinal)→Galvanization or powder coating ,painting →Packages


    Raw Material Test

    When the raw material arrives at the warehouse, the quality department must take the elongation test and the chemical composition analysis to make sure the raw material have meet all the standard that the needed before production even though mill certificate issued by mill factory has been provided.


    Bending

    Forming the cutted steel plate into the shape (circular or polygonal or other shape ) that as per specified in the drawing. This invention relates to forming devices and more particularly to devices or machines for bending longitudinally rolled sections or strips of metal stock to desired curvilinear shapes.


    Welding

    After molding, weld the steel plate together longitudinally. It adopts A.C.inverter control, with functions of stable running and fast traveling speed; The seam-tracking arc-guide mechanism is three-spindle system to guarantee the alignment without aberrancy; The main frame and welding machine are intergrated control, with flux auto-recovering system and it is easy to operate with high efficiency.


    Galvanization

    All poles internally and externally are to be hot-dip galvanized in accordance with requirement mentioned in the relevant drawing or specification
    Galvanization standard:
    Chinese standard GB/T 13912-2002 and American standard ASTM A123.


    The information to inquiry or purchase



    - Steel pole height
    - Dimension of the flange
    - Position and dimension of the service door
    - Cross arm type and length,the position to install in the steel pole
    - The method to fix the cross arm(use bolt to connect or use one or two template to weld in the steel pole to install the cross arm)
    - Wind speed
    - Destination port
    - Other.


    14m 800 Dan Electrical Transmission Power Pole Replacement Hot Dip Galvanization Q345
