    110KV Steel Tubular Pole Hot Dip Galvanized Electrical CO2 Welding Standard

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-SP-110KV
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : L/C, T/T or Western Union
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 1 week
    • Product Details
    • Company Profile

    110KV Steel Tubular Pole Hot Dip Galvanized Electrical CO2 Welding Standard

    110KV Hot Dip Galvanized Electrical pole Transmission Line pole


    Specifications:


    Products· 110KV Hot Dip Galvanized Electrical pole Transmission Line pole
    Type· Suspension Pole, Tensile Pole, Strain Pole , Angle Pole, Dead-end Pole, etc
    Voltage Grade· 10~500KV (10KV, 13.8KV,33KV, 35KV, 66KV, 110KV,132KV, 220KV, 230KV, 330KV, 500KV or Others )
    Shape· Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc),Tubular, Tapered
    Material·Q345B/A572,Min yield strength>=345MPA
    Q235B/A36,Min yield strength>=235MPA
    Wall thickness· 2~30mm
    Once Forming· 16m Once forming without joint
    Welding

    · Welding complies with AWS D1.1 standard.

    · CO2 welding or submerged arc auto methods

    · No fissure, scar, overlap, layer or other defects

    · Internal and external welding makes the pole more beautiful in shape

    · If customers need any other requirements of welding, we also can make adjustment ad your request

    Joint· Joint with insert mode, flange mode.
    Base plate· Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.
    Galvanization· Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.
    Painting· According to clients' request
    Life Period· More than 25 years, it is according to installing environment
    Advantages· Short construction cycle, less land occupation, low overall cost and easy maintenance.

    Product Details


    Steel tubular pole have been widely applied in the electrical power transmsion line and distribution industry.

    As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel pole have many advantages, such as: weather resistance, anti-corrosion, cost effective, environmentally friendly property, easy installation and maintaince and safety.



    Company Introduction


    JIANGSU HONGGUANG STEEL POLE CO., LTD.


    With over 15 Years of Experience/ Capable to Handle Volume Orders


    Exporting to Southeast Asia, Africa, Europe, Austrlia, the Middle East, South America, etc.
    Founded in 1998, Jiangsu Hongguang Steel Pole Co. Ltd (JSHG) specializes in manufacturing various steel structures. We manufacture a variety of products like Electrical Poles and Substation Structures for the power transmission industry; high masts and street lighting poles for illumination, which are widely used in expressways, airports, ports and docks, depots, parking lots and stadiums; tower poles for funicular railways; Telecommunication Monopole Towers for the telecommunication industry; Traffic
    Poles & Camera Poles & Advertising Structures for transportation Industry and Advertising Industry.




    Please feel free to contact us!

    Hot Dip Galvanized Steel Tubular Pole for Electrical Power Transmission and Distribution Line, Outdoor Lighting Project, Telecommunication Industry, Traffic System, Wind Power Project.pdf
