    Powder Coated Galvanized CCTV Camera Posts for Security / Traffic Surveillance

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-CP-02
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : Western Union, L/C, T/T
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 2 weeks per container after PO/drawing/prepayment confirmed
    • Product Details
    • Company Profile

    Powder Coated Galvanized CCTV Camera Posts for Security / Traffic Surveillance


    Powder Coated Galvanized CCTV Camera Posts for Security / Traffic Surveillance


    Specifications:

    Application

    • Traffic monitoring
    • Parking lot surveillance
    • Facility perimeter security and lighting
    • Prison yard observations
    • Airports
    • Business Area

    Outreach Arms Length

    • 1~6m

    Height

    • 1~10m

    Shape

    • Conical, Round, Polygonal ( Octagonal , Dodecagonal , Hexadecagonal , etc.) ,Tubular , Tapered

    Material


    • Normally Q345B / A572 , Minimum Yield Strength ≥ 345 N/mm²
    • Q235B / A36, Minimum Yield Strength ≥ 235 N/mm²
    • As well as Hot rolled coil from ASTM A572 GR65 , GR50 , SS400

    Wall thickness

    • 2~30mm

    Once Forming

    • 16m Once forming without joint

    Welding

    • Welding complies with AWS D1.1 standard.
    • CO2 welding or submerged arc auto methods
    • No fissure, scar, overlap, layer or other defects
    • Internal and external welding makes the pole more beautiful in shape
    • If customers need any other requirements of welding, we also can make adjustment ad your request

    Base plate

    • Base plate is square / round / Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.

    Surface Treatment

    • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123 or AS/NZS 4680:2006
    • Could be powder coated or painted according to clients' request

    Life Period

    • More than 25 years, it is according to installing environment

    Advantages

    • Short Construction Cycle
    • Low Overall Cost
    • Easy Installation and Maintenance
    • Solar and Wind Powered
    • Fashionable and Professinal Design
    • Weather Resistance
    • Anti-corrosion
    • ODM & OEM are available

    Product Details:

    Description:


    Cameras need to be at a required height to register everthing. Our Camera pole range with mounting heights of up to 15 meters, have been designed as a tapered pole to reduce shaft deflection, to ensure least possible movement for highly accurate and clear vision required for all surveillance and security needs.


    Being part of the city landscape, the camera pole varies from different cities. Our camera pole and monitor poles could be customed according to your requests. Meanwhile, we also have professional R&D engineers to design the poles for your reference.


    All poles are hot dip galvanized, and could be powder coated and painted as per customers’ requests.


    OEM and ODM are acceptable.


    Terms and Conditions


    1. Price Term: EXW, FOB, CFR or CIF.

    • The price includes pole shaft, base plate, crossarm and anchor bolt.
    • Shipping seaport: Shanghai Seaport.
    • Please provide drawings if you have so that we can calculate the accurate price for you.
    • We also provide design according to your requests, if you don't have drawings.

    2. MOQ: One 40FT Container.


    3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.


    4. Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed.


    5. Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom, or according to clients’ requirement.

    Powder Coated Galvanized CCTV Camera Posts for Security / Traffic Surveillance


    Please feel free to contact us!


    Camera CCTV Pole, Monitor Pole with Hot Dip Galvanization and Powder Coated or Painted.pdf
