    30m Height Telecommunication Towers Flange Connection For Broadcasting With Platforms

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : JSHG-TX
    Certification : XK11-001-00105X
    Price : negotiation
    Payment Terms : Western Union, L/C, T/T
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 2 weeks per container after PO/drawing/prepayment confirmed
    • Product Details
    • Company Profile

    30m Height Telecommunication Towers Flange Connection For Broadcasting With Platforms

    30m Height Telecomminication Towers for Broadcasting with Platforms


    Specifications:

    Application

    • Telecommunication, broadcasting, etc

    Shape

    • Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagon, etc)

    Material

    • Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65, ST-37, ST-44, ST-52, S355JR, S355J2G3, SS41, SS50, SS55 and others equivalent steel material

    Wall thickness

    • 2~30mm

    Once Forming

    • 16m Once forming without joint

    Welding

    • Welding complies with AWS D1.1 standard.
    • CO2 welding or submerged arc auto methods
    • No fissure, scar, overlap, layer or other defects
    • Internal and external welding makes the pole more beautiful in shape
    • If customers need any other requirements of welding, we also can make adjustment ad your request

    Joint

    • Joint with insert mode, flange mode.

    Base plate

    • Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.

    Surface Treatment

    • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123 or AS/NZS 4680:2006
    • Could be powder coated or painted according to clients' request

    Life Period

    • More than 25 years, it is according to installing environment

    Advantages

    • Cost-saving but Strong Practicability
    • Short Construction Cycle
    • Less Land Occupation
    • Easy Installation and Maintenance
    • Weather Resistance
    • Anti-corrosion
    • ODM & OEM are available

    Description:


    Telecommunication monopole tubular tower pole is the main carrier for communication signal launching and receiving. It is a sort of infrastructure construction for mobile transmission signal coverage. In order to response to the market demanding, our company invested large amount of hardware and software resource to produce steel telecommunication monopole which has been tested and approved by the General Administration of Quality Supervision, Inspection and Quarantine of PRC. In addition, we have successfully become a qualified supplier of China Tower Co., Ltd.

    30m Height Telecommunication Towers Flange Connection For Broadcasting With Platforms


    Engineering and Design Management


    “Design and technology,professional and common, software and hardware” is JSHG‘s design philosophy. We have established a close cooperative relationship with design institutions and companies in the same industry. Through close communication and explorations, our company took in advanced design concept, introducing domestic and foreign first-class design software, and attracting high-quality personnel.

    In the R&D Department, there are many experienced senior research & design staff and rigid development network, which ensure our design proposals meet customer demand, even exceed their expectations.

    Since the establishment, JSHG have put forward thousands of conical pole design proposals covering several industries and fields, such as power transmission industry, telecommunication industry, lighting industry, etc, which provides complete and strong technical support and service assurance.


    Raw Material :


    All our raw material are purchased from famous mill factories in China to ensure the quality which provide MILL INSPECTION CERTIFICATE with official stamp and signiture. In addition, our QC stuff make material test and metal identification test before manufacturing.


    Our Services

    Reply within 24 Working Hours

    Factory Direct Sale

    More than 15 Years Design & Manufacture Experience

    Capable to Handle Volume Orders

    High-Quality and Low-Price Products

    Provide Professional Design by Our Experienced R&D Engineers

    Rich Exporting Experience

    ODM, OEM Acceptable

    Technical Support by E-mail

    Calling service


    Hot Dip Galvanized Steel Tubular Pole for Electrical Power Transmission and Distribution Line, Outdoor Lighting Project, Telecommunication Industry, Traffic System, Wind Power Project.pdf
